BluePlug Max P

High-pressure permanent wireline- or tubing-set bridge plug

BluePlug Max CMR high-pressure wireline- or tubing-set cement retainer
Rated up to 10,000 psi [69 MPa]
Rated up to 300 degF [149 degC]
Validated to ISO 14310 and API Spec 11D1 V3

Effective barrier for remedial work and well abandonment

BluePlug Max P high-pressure permanent wireline- or tubing-set bridge plug is run in cased hole wells to create an effective well barrier against downhole fluids, including gas, enabling well abandonment or remedial cement injection above the plug.

overflow image

Reduce risks with validated designs

Based on field-proven designs, the BluePlug Max P bridge plug reduces risk of failure and premature setting with added features—such as antipreset slips—and ISO 14310 and API Specification 11D1 V3 validation. The compact, modular, cast iron construction reduces drillout times and enhances lifetime stability. In addition, the single-trip setting tool reduces time, risk, and cost. Versatile setting methods further simplify installation.

Plugs are available in quality grades Q1, Q2, and Q3.

Simplify your planning and optimize operations

The modular architecture of BluePlug Max P bridge plugs simplifies engineering designs across the entire range. You can select the plug best suited to your well environment while configuring certain components and subassemblies based on the specific challenges of your well. For example, you can customize the elastomer based on the chemical properties of your well fluids.

This standardization not only reduces lead times and costs, it enhances efficiency by enabling personnel to use a uniform deployment methodology. A kit is available for simple field conversion of the bridge plug into a BluePlug Max CMR high-pressure wireline- or tubing-set cement retainer.
