Blanking Plugs, Circulating Plugs, and Standing Valves

Name: Blanking Plugs Standing Valves
Brand: SLB

Control pressure and flow in single and dual completions

联系我们 Related Resources

Rated up to 10,000 psi [69 MPa]

Rated up to 300 degF [149 degC]

Hold pressure from above, below, or both

Slickline-retrievable blanking plugs are available to hold differential pressure in the tubing string from above, below, or both. They can be used in low- or high-pressure applications with differential pressures up to 10,000 psi [69 MPa]. High-temperature seals for operating above 300 degF [149 degC] are also available. Some blanking plugs can be easily converted to equalizing standing valves or circulating plugs.

Blanking Plugs

Hold pressure from above or below. Used in applications requiring bleeding off pressure in the tubing or circulating above the plugs. Also used as test plugs for testing tubing or packers.

Circulating Plugs

Hold pressure from below and allow flow from above. Used to plug formation pressure in the tubing string while providing adequate flow area for pumping into the formation.

Equalizing Standing Valves

Ball-and-seat-type check valves. Hold pressure from above while allowing flow through the plug from below. Used in intermittent gas lift wells to contain fluid in the tubing string during an injection cycle, or to set packers and test the tubing string.

Download PDFs for our Blanking Plugs, Circulating Plugs, and Standing Valves Offerings

Blanking Plugs	Circulating Plugs	Equalizing Standing Valves
Blanking PlugsA-Series blanking plug DB-1 WLP blanking plug DB-HP blanking plug DB-P blanking plug HP-A blanking plug	C-Series circulating plug	Equalizing Standing ValvesA-2- and M-Series equalizing standing valves HP-SV equalizing standing valve
