Product Sheet DPI Digital Slickline Production Logging Interface
The digital slickline production logging interface (DPI) provides operator ability to control acquisition of the downhole production logging tools.
DPI
Digital slickline production logging interface
Real-time control of sensor acquisition and tool status
The digital slickline production logging interface provides you the ability to control acquisition of the downhole production logging tools. It also provides real-time control of the depth correlation performed on site. You can control all stations and depth passes performed on site to know if depth is correct and data are properly recorded. When logging program is accomplished, you can perform a quick overview on site, even prior to pulling out of hole.
The digital PSP interface can be run with a standard PS Platform platform logging string, including two basic measurement sonde devices (PBMS-A and PBMS-B), gradiomanometer specific gravity profile tool (PGMS-B), and PS Platform platform inline spinner (PILS-A) and flow-caliper imaging sonde (PFCS-A).
| Specifications | |
|---|---|
| Specifications Temperature rating | 302 degF [150 degC] |
| Specifications Pressure rating | 15,000 psi [103.4 mpa] |
| Specifications Length (makeup) | 15-in [381 mm] |
| Specifications Length (transport, with end caps) | 20.4-in [517 mm] |
| Specifications Outside diameter | 1 11/16-in [43 mm] |
| Specifications Weight | 6.83 lbm [3.1 kg] |
| Specifications Service | H2S service |
| Specifications Top thread | 1 33/64-in 12 stub ACME (BEST) female |
| Specifications Bottom thread | 1 9/16-in 12 stub ACME special |
DPI provides operator real-time control of PSP logging data, acquired on depth.
