Case Study
overflow image
Malaysia, Asia, Onshore
overflow image
Aligned with United Nations Sustainable Development Goals: 12—Responsible consumption and production, 13—Climate action

Challenge: Design an acid gas removal system (AGRS) for an onshore processing facility to efficiently address variations in feed gas composition (12- to 25-mol% CO2 and H2S) and flow rate and deliver product gas with <8-mol% CO2.

Solution: Use CYNARA PN-1 dual-zoned acid gas removal membrane technology to achieve the required product gas specification with a system fabricated in multiple modular trains to efficiently manage dynamic swings in flow rate.


  • Delivered system on time.
  • Eliminated need for liquid chemicals (and the resulting weight, transportation, storage, and disposal issues).
  • Reduced installation cost (capex) by 50% and opex by more than USD 180 million over 20 years.
  • Enhanced operational flexibility to deliver stable outlet gas.
  • Exceeded designed hydrocarbon separation quality by 100%.
  • Exceeded designed flow capacity by 20%.

CYNARA PN-1 membrane technology was jointly developed by Petronas and Schlumberger. It is based on CYNARA acid gas removal membrane systems.

Products Used

Petronas Gas Plant Reduces Costs with Dual-Core Acid Gas Removal Membranes

CYNARA PN-1 membranes deliver high-quality separation despite variable high-CO2 concentration and gas flow rate

Size Reduction:
Reduced footprint by more than 60% compared with conventional solvent-based processes

Variations in flow rate and acid gas concentration present challenges at gas processing plant

Petronas Gas Berhad needed to design onshore gas processing facilities at the Terengganu gas terminal (TGAST) with the capability to process CO2-rich gas from offshore production and achieve the product gas specification of <8-mol% CO2. Significant variations in flow rate and acid gas concentration (12- to 25-mol% CO2 and H2S) in the feed gas streams required a technology that could dynamically handle wide swings in the feed gas conditions.

Schlumberger provided conceptual design scope for the CYNARA PN-1 dual-zoned acid gas removal membrane system. An economic comparison study of the proposed CYNARA PN-1 membrane technology versus conventional solvent-based processes showed that the former had 50% lower installation cost, more than 60% reduction in plot space, and 20-year estimated operating cost savings of more than USD 180 million. In 2013, Schlumberger was awarded the contract to complete the detailed design, fabricate, deliver, and provide site support for the proposed CYNARA PN-1 membrane system.

overflow image
The single-core membrane with a two-stage membrane system (left) is a conventional approach for acid gas removal. The CYNARA PN-1 dual-zoned acid gas removal membrane (right) offers the same separation in a single membrane element.

CYNARA acid gas removal membrane systems reduce installation and operating costs and increase efficiency

CYNARA acid gas removal membrane systems efficiently and selectively permeate acid gases to separate them from produced gas streams that contain 5- to 95-mol% acid gas. The membrane systems are compact, largely self-contained, and mounted on skids, which reduces installation costs. The use of these membrane systems also reduces operating costs by eliminating the need for liquid chemicals and the logistics of their transport, storage, and disposal.

The unique CYNARA PN-1 dual-zoned acid gas removal membrane, which was jointly developed with Petronas, works on the principle of diffusion and solubility-based separation. It combines two different membrane cores in a single 30-in-diameter membrane element, with each membrane optimized to selectively permeate different concentrations of acid gas endemic to the feed gas. The CYNARA PN-1 membrane permeates the highest concentrations of inlet acid gas in Zone 1 and directs lower concentrations of acid gas into Zone 2 to efficiently optimize the treatment of gas streams with irregular levels of CO2 and H2S.

Prior to deployment, the technology was tested and validated for three years at a Schlumberger-operated gas processing facility in Texas. During evaluation, it was demonstrated that the dual-core technology offers 8% to 10% more CO2 removal and throughput compared with standard 30-in single-core membranes and provides approximately four times higher CO2-removal capacity compared with 16-in membranes.

The Schlumberger team designed the gas plant’s AGRS to treat up to 700 MMcf/d of raw gas containing up to 25-mol% CO2 and deliver product gas with <8-mol% CO2, C3 = RSH (mercaptans), and C4 – RSH content. The system comprises two pretreatment trains of 350-MMcf/d nominal capacity, followed by five modular CYNARA PN-1 membrane sections that remove CO2 from inlet gas to produce the product gas (nonpermeate). The overall design of the CYNARA PN-1 acid gas removal membrane system was tailored for operation flexibility to address variations in feed gas composition and flow rate. With technical support from the Schlumberger global team of experts, the entire system was fabricated and delivered to Petronas by 2015, installed and commissioned on time in 2016, and began operation in early 2017.

overflow image
Relative flux and hydrocarbon (HC) separation performance data from the PM-1 primary membrane train shows very stable membrane performance overall despite the significant fluctuation in inlet feed gas conditions.

Performance of the CYNARA PN-1 acid gas removal membrane system exceeds design expectations

Operations data verified the anticipated significant flow rate swings in inlet gas. The modular design of the system easily addressed this issue, and after stabilization of operations, only three trains need to be used full time. Trains 4 and 5 are reserved for periods of increased flow rate.

In addition to the economic advantages derived from reduced installation costs and greater separation efficiency, data demonstrates stable performance of the membranes, consistent yield of product gas that meets required specification, and excellent overall performance that exceeds design expectations. Data from one of the five primary membrane trains, PM-1, shows overall flux capacity is at 120% and hydrocarbon separation performance is at 200% relative to the design. There is no evidence of decline in capacity or loss of separation quality. The design of the CYNARA PN-1 membrane system successfully meets the Petronas CO2 specification while retaining maximum hydrocarbons in the product gas.

Technical details

For more information, read SPE-192691.
